WY series cylindrical polishing machine

Main purpose and scope of application:

Cylindrical polishing machine is mainly used for the polishing of hydraulic pneumatic piston rod and roller shaft industry workpiece before and after electroplating. Cylindrical polishing machine can be installed with a variety of polishing wheels, such as, Chiba wheel, hemp wheel, nylon wheel, wool wheel, cloth wheel, PVA, etc., and PLC controls the one key operation of human-machine interface.

Main specification parameters:

(Special polishing equipment can be customized according to user requirements)

Project Model	WY-2	WY-3	WY-4	WY-5
Input voltage(v)	380V(three-phase four-wire)
Input power（kw)	13	13	13	13
Polishing wheel specification（mm)	250/30040/5032（Width can be assembled）
Chuck diameter(mm)	400
Polishing wheel speed(r/min)	3000
Spindle speed（r/min)	0-200
Machining diameter(mm)	50-600（Customizable）
X direction speed（m/min	0-8
Surface roughness (um)	Ra 0.02
Machining length（m）	2	3	4	5
Dry fan dust removal	have
Feeding mode of grinding head	Electric control for digital display
Load weight（KG）	1000(Customizable）
Machine tool Total weight about（kg)	2000	2800	3600	4400
Equipment Overall dimension（m)	51.61.5	61.61.5	71.61.5	81.61.5
