Products Detail
WX Series Single Grinding Head Round Tube Polisher
Main purpose and scope of application:
Round tube polisher is mainly used in hardware manufacturing, vehicle parts,hydraulic cylinders, steel and wood furniture, instrument machinery, standard parts and electroplating industries before and after the rust and polishing. Round tube polishing machine is the best
choice for round tube, round rod, long and thin shaft polishing. Round tube polisher can be installed a variety of polishing wheels, such as Chiba wheel, hemp wheel, nylon wheel, wool wheel, cloth wheel, PVA, etc., guide wheel stepless speed control, simple and convenient
operation, optimize the steel structure to make the performance more stable, the fan can be installed with the fan mouth.
Main specification parameters:
(Special polishing equipment can be customized according to user requirements)
-
WX Series Single Grinding Head Round Tube Polisher
Project
Model
WX-A1-60
WX-A1-120
WX-A2-60
WX-B1-60
WX-B1-120
Input voltage(v)
380V(Three phase four wire)
Input power（kw)
3.5
4.5
6
4.5
4.5
Polishing wheel
specification（mm)
250*40*32（Width can be assembled）
Guide wheel
specification(mm)
230*80
230*100
230*120
Polishing wheel
speed(r/min)
3000
Guide wheel speed(r/min)
0-120（Stepless speed regulation）
Machining diameter(mm)
1-120
50-180
1-120
1-120
50-180
Processing efficiency（m/min)
0-8
Surface roughness (um)
Ra 0.02
Wet water cycle dust removal
optional
have
optional
Dry fan dust removal
optional
have
optional
Machine tool total weight about（kg)
320
460
860
520
620
Equipment overall dimension（m)
0.7*0.8*1.0
0.8*0.9*1.0
1.2*0.9*1.5
1.0*0.9*1.0
1.1*1.0*1.0
-
Leštička kulatých trubek je běžně používané zařízení pro zpracování kovových výrobků. Životnost a výkon přímo ovlivňují efektivitu zpracování a kvalitu výrobku. Abychom zajistili dlouhodobý stabilní provoz leštičky kulatých trubek, musíme provádět následující údržbu:
- 1.Regular cleaning: A large amount of metal shavings and abrasive particles will be produced during the use of the round tube polishing machine. If it is not cleaned in time, it will increase the risk of equipment wear and failure. Therefore, it needs to be cleaned after each use, and the accumulated material and dust inside the equipment should be cleaned regularly.
- 2.Regular lubrication: Equipment failure caused by friction and wear is one of the main problems of the polishing machine, so it is necessary to regularly lubricate the friction parts of the equipment to reduce wear and keep the equipment running smoothly.
- 3.Check the electrical part: check the cables, wiring and switches of the electrical part to ensure that the electrical components work normally and safely, and replace damaged cables and parts in time.
- 4.Regular replacement of grinding wheels and abrasive belts: grinding wheels and abrasive belts directly affect the processing quality and equipment life, so they need to be replaced regularly according to the frequency and time of equipment use.
- 5.Regularly test the accuracy of equipment: regularly test the accuracy of equipment, such as measuring the size of parts, surface roughness and other indicators, and deal with abnormalities in time.
-
-
