WX-DL series large diameter hydraulic tube polishing machine

Hlavní účel a rozsah použití:

Round pipe polishing machine is mainly used for the derusting and polishing of hardware manufacturing, vehicle accessories, hydraulic cylinder, steel and wood furniture, instrument machinery, standard parts and industries before and after electroplating, from rough polishing to fine polishing. A variety of brown and white corundum grinding wheels and polishing wheels such as, Chiba wheel, hemp wheel, nylon wheel, wool wheel, cloth wheel, PVA, etc. can be installed in the round tube polishing machine. The guide wheel has stepless speed control, which is simple and convenient to operate. The steel structure is optimized to make the performance more stable. The reserved fan port can be equipped with a dust removal fan or a wet dust removal system, which can be matched with an automatic feeding and unloading mechanism according to the length of the processed parts. This device It can be equipped with grinding wheel to grind pin and remove oxide skin (peeling off) on the surface of round steel and pipe with serious defects.

Hlavní parametry specifikace:

(Speciální leštící zařízení lze přizpůsobit podle požadavků uživatele)

Projekt Modelka	WX-DL-2	WX-DL-4	WX-DL-6	WX-DL-8	WX-DL-10
Vstupní napětí (v)	380V (třífázový čtyřvodičový)
Vstupní výkon (kw)	13.2	22.2	30.7	38.7	46.7
Leštící kotouč specifikace (mm)	250/30040/5032（šířku lze sestavit）
Vodicí kolo specifikace (mm)	110
Leštící kotouč rychlost (ot./min)	3000
Otáčky vodícího kola (ot./min)	Plynulá regulace rychlosti
Průměr obrábění (mm)	20-360
Účinnost zpracování（m/min)	0-8
Drsnost povrchu (um)	Den 0.02
Délka zpracování (mm)	Determined by bracket length （0.3-12）
Suché odstranění prachu z ventilátoru	volitelný
Odstranění prachu z mokrého vodního cyklu	volitelný
Brusná hlava režim krmení	Digital display electromagnetic hydraulic control
Způsob seřízení pasivního vodícího kola	Manuální/elektrický/automatický volitelný
Machine tool total weight about（kg)	2000	3000	4000	5000	6000
Equipment dimension(m)	1.31.21.5	2.61.21.5	3.91.21.5	5.21.21.5	6.51.21.5

The horizontal type of multi-station round pipe polishing machine mainly processes shorter workpieces with smaller diameters. The operation is simple, the speed is stepless speed regulation drive, suitable for polishing different requirements of the change and adjust the transmission speed. Mainly for crafts processing plant, hardware processing plant, bathroom processing plant, electronic processing plant and other customer groups to use.

Horizontal cylindrical tube polishing machine to achieve automatic surface polishing treatment, suitable for small workpieces, metal workpieces automatic polishing surface gloss and burr removal. It has the characteristics of high efficiency, good finish and wide range of abrasive consumables. It should be noted that during the polishing process, do not reach into the polishing area, and the machine must be turned off when replacing or correcting the polishing wheel, and then operate after completely continuous work.

Automatic CNC large diameter hydraulic round pipe polishing machine introduction:

1,The round tube polishing machine has high efficiency, good finish, extensive and durable abrasive consumables, etc.

2, the machine has the advantages of simple and convenient operation, stable product performance and low noise, and is well received by the majority of users. Optional cooling system and dust collection system are used to meet different industries. This machine reserved fan port users can also install their own dust removal fan.

3, the machine guide wheel rotation using stepless speed regulation, can better meet the different diameters, different lengths of workpiece grinding or polishing. Because the guide wheel of the machine rotates by stepless speed regulation, the polishing workpiece is more efficient, the finish is better, and the abrasive consumables are extensive and durable. The scope of application: Used in industries: hardware, electroplating, furniture, standard parts, auto and motorcycle parts and hydraulic transmission and other manufacturing industries. It is used for grinding or polishing the outer surface of various round tubes, round rods, shafts and rods. It is suitable for polishing the workpiece after processing by centerless cylindrical grinding machine.
