What is the main application of this polishing machine?

This machine is specifically designed to remove rust, oxidation, and surface imperfections from the outer surface of stainless steel (SS) round pipes, leaving a clean and polished finish.

What pipe sizes can the machine accommodate?

The machine can process a wide range of pipe diameters, typically from [insert minimum] mm to [insert maximum] mm, depending on the model specifications.

Does the machine support adjustable polishing speed?

Yes, it features variable speed controls to match different material conditions and polishing requirements, ensuring optimal results.

What kind of surface finish can be achieved?

The machine can deliver a variety of finishes, from brushed (satin) to mirror polish, depending on the abrasives or polishing wheels used.

What maintenance is needed to keep the machine in good condition?

Routine maintenance includes cleaning dust and debris, replacing worn polishing belts or wheels, checking motor performance, and lubricating moving parts regularly.

High Quality Ss Pipe Polishing Machine Wholesale Manufacturer

New SS pipe outer round rust removal polishing machine

Round pipe polishing machine is mainly used in hardware manufacturing, vehicle parts, steel and wood furniture, instrument machinery, standard parts and other industries before and after electroplating rust and polishing, is a good choice for round pipe, round rod, slender shaft polishing.

Products Detail

Read More About high quality table top centerless grinder

WX-DWZ Series Multi-station Round Tube Polishing Machine

Main purpose and scope of application:

Round pipe polisher is mainly used for the derusting and polishing of hardware manufacturing, vehicle accessories, hydraulic cylinder, steel and wood furniture, instrument machinery, standard parts and industries before and after electroplating, from rough polishing to fine polishing. Round pipe polisher is the best choice for polishing the round pipe, round rod and slender shaft. The round tube polisher can be equipped with a variety of polishing wheels, such as, Chiba wheel, hemp wheel, nylon wheel, wool wheel, cloth wheel, PVA etc. the guide wheel is stepless speed control, simple and convenient operation, and the steel structure is optimized to make the performance more stable. The reserved fan port can be equipped with a dedusting fan or a wet dedusting system, which can be matched with an automatic loading and unloading mechanism according to the length of the processed parts.

Main specification parameters:

(Special polishing equipment can be customized according to user requirements)

Project Model	WX-DWZ-2	WX-DWZ-4	WX-DWZ-6	WX-DWZ-8	WX-DWZ-10
Input voltage(v)	380V(Three phase four wire)
Input power（kw)	8.6	18	26.5	35.5	44
Polishing wheel specification（mm)	250/30040/5032（Width can be assembled）
Guide wheel specification(mm)	100*200
Polishing wheel speed(r/min)	3000
Guide wheel speed(r/min)	Stepless speed regulation
Machining diameter(mm)	4-100
Processing efficiency（m/min)	0-20
Surface roughness (um)	Ra 0.02
Processing length（mm）	100-6000
Wet water cycle dust removal	optional
Dry fan dust removal	optional
Feeding mode of grinding head	Digital display electric adjustable
Machine tool Total weight about（kg)	800	1600	2400	3200	4000
Equipment Overall dimension（m)	1.41.21.0	2.61.21.0	3.81.21.0	5.01.21.0	6.21.21.0

Read More About high quality old centerless grinding machine

Read More About high quality centerless grinder cincinnati

The machine is completely closed dust-proof structure, good quality, stable operation; Simple operation, easy maintenance, polishing workpiece finish higher favored by domestic and foreign customers! The operator shall not remove the handle without authorization. When stopping, the handle can be loosened only after the high-speed polishing machine has completely stopped rotating. Do not use the polishing pad with dust and dirt. Too much dirt polishing pad can not be cleaned, with timely replacement. When replacing or installing the polishing pad, cut off the power supply.

Automatic round tube mirror polishing machine guide wheel is stepless speed control, polishing efficiency is easy to control. Optimized machine design, more stable performance, less noise multi-station round tube polishing machine Operation Horizontal multi-station round tube polishing machine is a large round tube polishing machine with multiple grinding heads as one, suitable for multiple polishing of any workpiece with different sizes and diameters.

Read More About high quality metal polishing machine price

The polishing process of the round tube polishing machine needs to first fix the round tube to be polished on the workbench, and then rotate the polishing material through the workbench and the motor to grind the polishing material on the surface of the round tube. The whole process needs to control factors such as polishing pressure, rotational speed, and spraying amount of polishing fluid, so as to achieve the best polishing effect.

The main function of the round tube polishing machine is to polish the round tube, round rod and slender shaft. Polishing using dry polishing form, each time can complete different thickness polishing. This machine can be used for high quality sanding and polishing of aluminum, iron, copper and stainless steel surfaces.

The workpiece processed by the circular tube polishing machine has high brightness and does not affect the original size of the workpiece, which is especially suitable for the high-gloss polishing of the workpiece processed by the centerless grinder. Round tube polishing machine has the characteristics of high working efficiency. As the main polishing tool in life now, the polishing effect is very good. And whether it is polished furniture and various hardware tools, etc., there will be no damage and defects, easy to use.

Read More About high quality old centerless grinding machine

Need Our Services And Quotes?
Request a Quote

If you are interested in our products, you can choose to leave your information here, and we will be in touch with you shortly.
- name*
- email*
- phone*
- message*

Outer Round Rust Removal Polishing Machine Restores Tubes Like New

We’ve been using the outer round rust removal polishing machine for steel and iron tubes that come in with surface corrosion. The results are amazing — rust is completely removed, and the finish is smooth and ready for further processing or coating. It has helped us reduce rework and material waste.

Michael Turner

Production Manager, SteelFlow Industrial Co.

Stable and Effective Outer Round Rust Removal Polishing Machine

This outer round rust removal polishing machine is incredibly stable during operation. It handles different pipe diameters easily and removes surface rust thoroughly without damaging the material. Our polishing process is now faster and more uniform than ever before.

Li Ming

Workshop Supervisor, Tianjin SurfaceTech Ltd.

High-Performance Outer Round Rust Removal Polishing Machine for Heavy Use

We use this machine in a high-output environment, and it consistently performs under pressure. The outer round rust removal polishing machine is rugged, efficient, and has minimal vibration. It’s especially good for preparing pipes for welding or finishing.

Carlos Mendez

Operations Lead, PipeClean Systems Inc.

Outer Round Rust Removal Polishing Machine Greatly Improved Our Efficiency

This machine has saved us hours of manual labor. The outer round rust removal polishing machine quickly eliminates rust and leaves a polished surface in one pass. It’s a perfect solution for prepping large quantities of tubes before fabrication.
