What materials can this polishing machine process?

It is designed to polish steel pipes, stainless steel tubes, and flat plates such as stainless steel sheets, delivering various surface finishes.

What makes this a “high-speed” polishing machine?

It is equipped with powerful motors and fast-rotating polishing wheels, allowing for quick and efficient material removal and surface finishing.

What surface finishes can be achieved?

The machine can achieve brushed, satin, matte, or even mirror finishes, depending on the abrasives and polishing heads used.

Is it suitable for continuous or industrial production?

Yes, this machine is built for heavy-duty and continuous operation, making it ideal for high-volume production lines in industrial settings.

Can it handle both round pipes and flat plates with one setup?

Some models are multi-functional, capable of polishing both round and flat surfaces. However, tooling adjustments may be needed when switching between shapes.

High Speed Polishing Steel Pipe Stainless Steel Flat Plate Polishing Machine

ម៉ាស៊ីនប៉ូលាដែកបំពង់ដែកអ៊ីណុកល្បឿនលឿនប៉ូឡូញល្បឿនលឿន

ម៉ាស៊ីនមានលក្ខណៈនៃបរិមាណតូច ប្រតិបត្តិការសាមញ្ញ និងការបញ្ចប់ដ៏ល្អ។ វាជាជម្រើសដ៏ល្អមួយសម្រាប់ការប៉ូលាគ្រឿងម៉ាស៊ីន។ វាអាចប៉ូលាដែកអ៊ីណុក បន្ទះដែក និងបន្ទះអាលុយមីញ៉ូមស្ពាន់។

Products Detail

Xieli Machinery High speed polishing steel pipe stainless steel flat plate polishing machine price

PM series plane polishing machine

Main purpose and scope of application:

◆ Machine has the characteristics of small volume, simple operation and good finish. It is an ideal choice for polishing plane workpieces. It can polish stainless steel, iron plate and copper aluminum plate.

Main specification parameters:

(Special polishing equipment can be customized according to user requirements)

Voltage	380V	Speed of worktable	Adjustable
Machining workpiece size (L × W×H)	500240350mm	Width of with wheel	100mm
Distance from table surface to spindle center	500mm	Diameter of with wheel	300mm
Bearing capacity of worktable	200kg	Spindle speed	2800 rpm
Size of the worktable surface	800×260mm	Spindle motor	3.0kw
T-groove of worktable	mm×n：12×3	Overall dimension of machine tool(L × W× H)	1000×800×1400mm
Surface roughness	Ra 0.02	Weight	750kg

1.Xieli Machinery High speed polishing steel pipe stainless steel flat plate polishing machine price

Xieli Machinery High speed polishing steel pipe stainless steel flat plate polishing machine price

Need Our Services And Quotes?
Request a Quote

If you are interested in our products, you can choose to leave your information here, and we will be in touch with you shortly.
- name*
- email*
- phone*
- message*

Flat Plate Polishing Machine Produces A Smooth, Mirror-Like Finish

We use the flat plate polishing machine for stainless steel panels, and it delivers an outstanding mirror finish. The polishing is uniform across the entire surface, and the machine is both stable and efficient during long hours of operation.

James Parker

Production Supervisor, ShineMetal Fabricators

Highly Reliable flat plate polishing machine for Industrial Applications

This machine is a workhorse in our shop. It handles various metal plates with consistent pressure and polish quality. Setup is straightforward, and maintenance has been minimal. Great value for high-volume polishing tasks.

Li Mei

Operations Manager, Chenghua Metalworks

Flat Plate Polishing Machine Greatly Improves Surface Quality

We’ve seen a huge improvement in the final appearance of our flat plates after switching to this polishing machine. The results are smooth and professional-grade, perfect for architectural and decorative applications.

Ahmed Nassar

Quality Control Manager, NovaSteel Solutions

Efficient And Easy-To-Use Flat Plate Polishing Machine

The flat plate polishing machine is intuitive to use and delivers excellent results every time. It’s helped reduce manual labor and improved our consistency. We’re very happy with its performance and durability.
